PAXT0110 Red Lion Industrial Automation Components

Red Lion PAXT0110 Red Lion PAXT0110 is a digital timer from the PAX series, designed with a 1/8 DIN (96x48mm) form factor and features 14.2mm red digits with communication capability. It operates on a supply voltage range of 85-250Vac, accommodating various standard voltages such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. The dimensions of this timer are specified as 1/8 DIN horizontal, measuring W96mm x H48mm (3.80" x 1.95"). It offers a degree of protection rated at IP65 NEMA 4X, ensuring a high level of protection against dust and water ingress. Additionally, it is equipped with 3 x digital inputs (Sink/Source) for user input, enhancing its versatility in application.
Red Lion

Part#:PAXT0110

Manufacturer:Red Lion

Product Lifecycle:Active

Get a quick Quote!

Red Lion PAXT0110 is a digital timer from the PAX series, designed with a 1/8 DIN (96x48mm) form factor and features 14.2mm red digits with communication capability. It operates on a supply voltage range of 85-250Vac, accommodating various standard voltages such as 100Vac, 110Vac, 120Vac, 200Vac, 208Vac, 220Vac, 230Vac, and 240Vac. The dimensions of this timer are specified as 1/8 DIN horizontal, measuring W96mm x H48mm (3.80" x 1.95"). It offers a degree of protection rated at IP65 NEMA 4X, ensuring a high level of protection against dust and water ingress. Additionally, it is equipped with 3 x digital inputs (Sink/Source) for user input, enhancing its versatility in application.

About the manufacturer: Red Lion is one of the manufacturers that offers Industrial Automation Components that you can order at marketplace.quotebeam.com. Red Lion Controls has been a reliable supplier to customers globally for over 40 years. Our highly regarded industrial automation and networking solutions provide vital information and controls to improve efficiency, seamlessly integrating with various devices and applications.

Check out the PAXT0110 Red Lion price in the box on the right side or send a quick quote.

Product Details

  • Primary brand
    Red Lion
  • Main function
    Thermometer (Digital)
  • Frequency
    20Hz analog input sampling rate
  • Product series / family name
    Process indicators
  • Design
    3 user inputs 1/8 DIN horizontal (96x48mm) 14.2mm green digits communication capability
  • Functions
    Universal digital temperature meter
  • Benefits
    Process / voltage / current / temperature / strain gage inputs Variable intensity display 16 point scaling for non-linear processes Programmable function keys/user inputs 9-digits totalizer (integrator) with batching Optional custom units overlay with bac
  • Digital inputs
    3 x digital inputs (Sink/Source) (USER INPUT)
  • Order code / Manufacturer SKU
    PAXT0110
  • Dimensions
    1/8 DIN horizontal (W96mm x H48mm / 3.80" x 1.95")
  • Compliant with standard(s)
    CE IEC 60068-2-6 (vibration) EN 61326-1 immunity to industrial locations EN 61010-1 EN 61010-2-030 UL Listed RoHS compliant
  • Degree of protection
    IP65 NEMA 4X
  • Supply voltage (DC)
    11-36Vdc (12Vdc / 24Vdc)
  • Analog outputs
    1 x analog output (retransmission)
  • Analog inputs
    1 x analog input (4-20mA / 0-20mA / 0-10Vdc / Thermocouple types T; E; J; K; R; S; B; N; C / Pt100 / Ni120 RTDs DC; 16-bits conversion; 0.12%...0.7% accuracy)
  • Sub-range name
    PAX series
  • Display
    1 row x 6-digits green characters (14.2mm / 0.56" high) LED display

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
