BN 325-R-1279 Schmersal Electronic Components
Part#:BN 325-R-1279
Manufacturer:Schmersal
Alt. Part#:101147091
Product Lifecycle:Active
Get a quick Quote!
Magnetic reed switch; Cable output left and 2 shielding plates; Actuation from front; Non-contact principle; 1 Reed contakts; Long life; Actuating surface and direction of actuation marked by switch symbol; 85 mm x 26 mm x 24 mm; Thermoplastic enclosure;
About the manufacturer: Schmersal is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Schmersal produces a wide range of high-quality switchgears specifically engineered to protect machinery and facilities in industrial automation and the elevator industry.
Check out the BN 325-R-1279 Schmersal price in the box on the right side or send a quick quote.
Product Details
- Active principle Magnetic drive
- Mounting rear with 2 threaded bolts
- Length of sensor 24 mm
- Ambient temperature, maximum +70 °C
- Switching element bistable contact
- Housing construction form rectangular
- Repeat accuracy R R 0.3 mm
- Restistance to shock 50 g / 11 ms
- Bounce duration, minimum 0.3 ms
- Suitable for elevators Yes
- Actuating speed, maximum 18 m/s
- Length of cable 1 m
- Resistance to vibrations to EN 60068-2-6 10 … 55 Hz, amplitude 1 mm
- Versions Reed contacts
- Actuating element Magnet
- Latching Yes
- Terminal Connector Cable outlet left and 2 shielding plates
- Degree of protection IP67
- Switching frequency, maximum 300 Hz
- Gross weight 98 g
- Notice (Switch distance Sn) Actuating distance up to 55 mm depending on actuating magnet and version. The specified switching distances are applicable for the actuation of individually mounted components without ferromagnetic influence. A change of the distance, either positive or n
- Height of sensor 26 mm
- Actuating panels front side
- Enclosure material Glass-fibre, reinforced thermoplastic
- Width of sensor 85 mm
- Switching current, maximum 3 A
- Number of snap-in contacts 1
- Switching voltage, maximum 250 VAC
- Bounce duration, maximum 0.6 ms
- Mechanical life, minimum 1,000,000,000 Operations
- Switch distance Sn 5 mm … 55 mm, 2 x BP 21S = 20 ... 55 mm, BP 34S = 10 ... 25 mm
- Switching capacity, maximum 120 VA
- Ambient temperature, minimum -25 °C
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents BN 325-R-1279 Specs
