12512EG3G445T-W22 WEG AC Motors
Part#:12512EG3G445T-W22
Manufacturer:WEG
Alt. Part#:7891327885158
Product Lifecycle:Active
Get a quick Quote!
W22 Super Premium Efficiency 125 HP 6P 444/5T 3Ph 460 V 60 Hz IC411 - TEFC - Foot-mounted
Check out the 12512EG3G445T-W22 WEG price in the box on the right side or send a quick quote.
Product Details
- Output Rating125 HP
- Rated Speed1190 rpm
- Number of Poles6 Pole
- Voltage460 V
- Flange TypeWithout
- Slip 0.83 %
- Number of Poles 6
- Rated speed 1190 rpm
- Temperature rise 80 K
- Noise level² 69.0 dB(A)
- Terminal box¹ Left position
- Frequency 60 Hz
- Locked rotor torque 240 %
- Mounting F-1
- Voltage 460 V
- Output 125 HP
- Breakdown torque 260 %
- Rotation¹ Both (CW and CCW)
- Rated voltage 460 V
- Design A
- Duty Cycle Cont.(S1)
- Number of poles 6
- L. R. Amperes 1155 A
- LRC 7.6x(Code J)
- Standard NEMA MG-1
- Synchronous speed 1200 rpm
- Rated current 152 A
- Locked rotor time 45s (cold) 25s (hot)
- Insulation Class F
- Output rating 125 HP
- Frame 444/5T
- No load current 72.0 A
- Service factor 1.25
- Flange Without
- Moment of inertia (J) 114 sq.ft.lb
- Starting Method Direct On Line
- Enclosure IC411 - TEFC
- Rated torque 552 ft.lb
- Ambient temperature -20°C to +40°C
- Degree of Protection IP55
- Altitude 1000 m.a.s.l.
- Approx. weight³ 2042 lb
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents 12512EG3G445T-W22 Specs
