S18DLGGGP Banner Electronic Components
Part#:S18DLGGGP
Manufacturer:Banner
Product Lifecycle:Active
Get a quick Quote!
S18 Daylight Visible EZ-LIGHT - 18 mm - IP67, Three Color: Green Green Green, 10-30 V dc PNP Input, 4 Wire 2 m Cable
About the manufacturer: Banner is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the S18DLGGGP Banner price in the box on the right side or send a quick quote.
Product Details
- Power DC
- Lumens Color 2 2.3
- Color Option 3 Green
- Physical Dimensions (LxWxH or DxH mm) 23.5 x 35.7
- Feature: Audible No
- Pro-Editor Compatible (Discrete) No
- Primary Housing Material Polycarbonate
- Animation Option 1 Solid On
- Number of Input Pins/Conductors 4
- Primary Housing Color Black
- Multi-Color Device Single Color On
- Mounting Thread M18 x 1.0
- Lumens Color 1 2.3
- Color 2 - Wavelength/Color Temp/Coordinates 525 nm
- Input Type PNP
- Indication Yes
- Product Size (mm) 18
- Color 1 - Wavelength/Color Temp/Coordinates 525 nm
- Supply Voltage 10-30 V dc
- IO Link No
- Housing Style Barrel Mount - Flat Window
- Color Option 2 Green
- Lumens Color 3 2.3
- NEMA Type and UL Type Rating NEMA and UL 4X, 13
- Indication Intensity High Brightness & Daylight Visible
- Power Source DC
- Connection Cable
- Max Current Color (mA) 25
- Max Op. Temperature (°C) 50
- Modbus RTU No
- Cable Length (m) 0.15
- Color Option 1 Green
- Color 3 - Wavelength/Color Temp/Coordinates 525 nm
- Environmental Rating IP67; IP69
- Feature: Hazardous Area No
- Number of Colors / Segments 3
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color Technology Standard LED
- Max Input Response Time (ms) 1
- Min Op. Temperature (°C) -40
- Feature: Chemical Resistant No
- Feature: Washdown Rated Yes
- Primary Window Material Polycarbonate Clear
- Wireless No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents S18DLGGGP Specs
