WLS27XY570DSQ Banner Signal Towers
Part#:WLS27XY570DSQ
Manufacturer:Banner
Alt. Part#:95912
Product Lifecycle:Active
Get a quick Quote!
WLS27 Work Light Strip; Diffused Window; Length: 570 mm; Voltage: 12-30 V dc; Environmental Rating: IP66; IP67; IP69K; Color: Yellow; 4-pin M12 Integral QD
About the manufacturer: Banner is one of the manufacturers that offers Signal Towers that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the WLS27XY570DSQ Banner price in the box on the right side or send a quick quote.
Product Details
- Weight453.592 g
- Country Of OriginMX
- Power Source DC
- Quick Disconnect Type M12 (Euro)
- Feature: Washdown Rated Yes
- Illumination Yes
- Max Current Color (mA) 1600
- Physical Dimensions (LxWxH or DxH mm) 27.0 x 633.5
- Wireless No
- Primary Housing Material FDA Copolyester
- Dimming Option High-Low-Off
- Illuminated Length (LxWxH mm) 570.0
- IO Link No
- Housing Style Linear Strip
- Lumens Color 1 1300
- Storage Temp (°C) -40 to 70
- Modbus RTU No
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color Technology Standard LED
- Supply Voltage 12-30 V dc
- Feature: Audible No
- Mounting Thread No Thread
- Color 1 - Wavelength/Color Temp/Coordinates 590 nm
- Min Op. Temperature (°C) -40
- Pro-Editor Compatible (Discrete) No
- Power DC
- Connection Integral QD
- Environmental Rating IP66; IP67; IP69
- Multi-Color Device Single Color On
- Number of Colors / Segments 1
- Number of Input Pins/Conductors 4
- Feature: Hazardous Area No
- Product Size (mm) 27
- Color Option 1 Yellow
- Max Op. Temperature (°C) 70
- Feature: Chemical Resistant Yes
- Animation Option 1 Solid On
- Primary Window Material Copolyester Diffused
- Feature: Quick Disconnect Yes
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
WLS27XY570DSQ Description
Banner Engineering WLS27XY570DSQ is a single color series industrial sealed LED task light designed for a variety of applications. It features a diffused window with 1-color yellow LED illumination, suitable for providing clear visibility in industrial environments. This task light operates on a supply voltage range of 12Vdc to 30Vdc, with a nominal voltage of 24Vdc, and has a luminous flux of 1300 lumens. The product dimensions are L570mm x D27mm, with a cylindrical linear strip shape and a 27mm tube diameter. It is constructed from FDA-grade copolyester for both the diffused window and the outer housing, ensuring durability and suitability for a wide range of environments. The WLS27XY570DSQ is pre-equipped with a 4-pin M12 Euro-style quick disconnect (QD) connector for easy installation. It offers a high degree of protection with IP66, IP67, and IP69K ratings, making it resistant to dust, water, and high-pressure washdowns. The task light can operate in ambient air temperatures ranging from -40°C to +70°C and includes 1 x digital input (12-30Vdc) for color control. The current consumption is rated at 1.6A.
Related documents WLS27XY570DSQ Specs
