02018XT3H256TC WEG AC Motors
Part#:02018XT3H256TC
Manufacturer:WEG
Alt. Part#:7909492061960
Product Lifecycle:Active
Get a quick Quote!
W21 Explosion-proof Motor NEMA Premium Efficiency 20 HP 4P 256TC 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted
Check out the 02018XT3H256TC WEG price in the box on the right side or send a quick quote.
Product Details
- Output Rating20 HP
- Rated Speed1770 rpm
- Number of Poles4 Pole
- Voltage575 V
- Flange TypeC
- Output 20 HP (15 kW)
- Rated torque 59.3 ft.lb
- Duty Cycle Cont.(S1)
- Voltage 575 V
- Rated voltage 575 V
- LRC 7.5x(Code J)
- Design B
- Noise level² 69.0 dB(A)
- Number of poles 4
- Slip 1.67 %
- No load current 9.44 A
- Altitude 1000 m.a.s.l.
- Flange C
- Ambient temperature -20°C to +40°C
- Approx. weight³ 377 lb
- Number of Poles 4
- Breakdown torque 300 %
- Mounting F-1
- Output rating 20 HP
- Rated speed 1770 rpm
- Temperature rise 80 K
- Service factor 1.15
- L. R. Amperes 150 A
- Insulation Class F
- Degree of Protection IP55
- Terminal box¹ Left position
- Frequency 60 Hz
- Moment of inertia (J) 2.89 sq.ft.lb
- Standard NEMA MG-1
- Rated current 20.0 A
- Locked rotor torque 300 %
- Starting Method Direct On Line
- Synchronous speed 1800 rpm
- Frame 256TC
- Locked rotor time 36s (cold) 20s (hot)
- Enclosure IC411 - TEFC
- Rotation¹ Both (CW and CCW)
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
