SM30SRLMHSQD Banner Electronic Components

Banner SM30SRLMHSQD Banner Engineering SM30SRLMHSQD is a photo-electric sensor designed for through-beam system applications with an "A" modulation frequency. This sensor, part of the SM30 series, functions as a receiver alone and is housed in stainless steel for durability. It features a pre-equipped 4-pin 7/8" mini connector for easy connection and operates on a supply voltage range of 10Vdc to 30Vdc, with nominal voltages of 12Vdc and 24Vdc. The sensor can operate in ambient air temperatures ranging from -40 to +70°C and is protected to IP67 NEMA 6P standards, ensuring its operation in challenging environments. Its M30 cylindrical threaded/barrel shape allows for straightforward installation. The SM30SRLMHSQD offers one digital output (PNP/NPN transistor), can detect objects up to 150m away, and operates with infrared light at a wavelength of 880 nm. It has a rapid response time of 1ms / 0.001 s and supports both Light-ON and Dark-ON operating modes.
Banner

Part#:SM30SRLMHSQD

Manufacturer:Banner

Product Lifecycle:Active

Get a quick Quote!

Banner Engineering SM30SRLMHSQD is a photo-electric sensor designed for through-beam system applications with an "A" modulation frequency. This sensor, part of the SM30 series, functions as a receiver alone and is housed in stainless steel for durability. It features a pre-equipped 4-pin 7/8" mini connector for easy connection and operates on a supply voltage range of 10Vdc to 30Vdc, with nominal voltages of 12Vdc and 24Vdc. The sensor can operate in ambient air temperatures ranging from -40 to +70°C and is protected to IP67 NEMA 6P standards, ensuring its operation in challenging environments. Its M30 cylindrical threaded/barrel shape allows for straightforward installation. The SM30SRLMHSQD offers one digital output (PNP/NPN transistor), can detect objects up to 150m away, and operates with infrared light at a wavelength of 880 nm. It has a rapid response time of 1ms / 0.001 s and supports both Light-ON and Dark-ON operating modes.

About the manufacturer: Banner is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the SM30SRLMHSQD Banner price in the box on the right side or send a quick quote.

Product Details

  • Connection
    Integral QD
  • Power
    DC
  • Delay at Power-up (ms)
    N/A
  • Indicator
    LEDs
  • Sensing Mode (Detailed)
    Receiver
  • Quick Disconnect Type
    7/8 in. (Mini)
  • Max Op. Relative Humidity [%]
    90% @ 50°C
  • Feature: Audible
    No
  • Input/Output
    Discrete
  • Output response time (ms)
    1
  • IP Rating
    IP67
  • DeviceNet
    No
  • Primary Housing Material
    Stainless Steel
  • Operation
    Light/Dark Operate
  • Special Feature: Water Detection
    No
  • IO Link
    No
  • Sensing Beam
    Infrared LED
  • Max Op. Temp. (°C)
    70
  • Repeatability (µs)
    1000
  • Feature: Timing (Hold/Delay)
    No
  • Outputs
    Bipolar (NPN & PNP)
  • Min Op. Temp. (°C)
    -40
  • NEMA Rating
    NEMA 6P
  • Sensing Mode (General)
    Opposed
  • Power Supply/Supply Voltage
    10-30 V dc
  • Number of Pins
    4
  • Feature: Encapsulated
    No
  • Max Sensing Distance (mm)
    150000
  • Special Feature: Intrinsically Safe
    No
  • Adjustments
    N/A
  • Housing Style
    Barrel
  • Lens Material
    Acrylic
  • Special Feature: Remote Teach
    No
  • Barrel Diameter (mm)
    30
  • Feature: Hazardous Area
    No
  • Feature: Chemical Resistant
    Yes
  • Opposed Mode Emitter/Receiver
    Receiver

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging

Related documents SM30SRLMHSQD Specs

SM30SRLMHSQD SM30 High-Power Series-1630949355484.pdf
