YA453L90 Hubbell Electronic Components
Part#:YA453L90
Manufacturer:Hubbell
Product Lifecycle:Active
Get a quick Quote!
Cu Tubing Compression Terminal, 1 Hole W/O InspWindow,1300 Kcmil, 3/4" Stud, Uninsulated, Standard Barrel.
About the manufacturer: Hubbell is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Hubbell offers a variety of products that are specifically designed to tackle challenges faced by businesses, increase energy efficiency, enhance safety, perform well in harsh environments, streamline wiring organization, and improve grounding systems in and around buildings.
Check out the YA453L90 Hubbell price in the box on the right side or send a quick quote.
Product Details
- Connector Type Terminal
- Plated Y
- UPC 12 Digit 7818103129333
- Dimension - L Length Overall mm 67 mm
- Dimension - Strip Length inch 2-1/16 in
- Voltage - Maximum 35000
- Minimum Pack Quantity 1
- Industry Standard(s) UL 486A-486B
- Feature - Barrel Style Chamfered
- Dimension - Height inch 3.89 in
- Dimension - Pad Width inch 2.53 in
- Physical Attribute - Tongue Type straight
- Dimension - Z inch 0.77 in
- UL Listed Yes
- Standards - RoHS Compliance Status CM
- Feature - Barrel Type Standard
- Dimension - Length Overall inch 2.65 in
- Physical Attribute - Number of Holes 1
- Dimension - N inch 0.75 in
- Dimension - Stud Size inch 3/4 in
- Dimension - Thread Size 3/4 in
- Conductor - Copper Str Size 1300 Kcmil
- Die Index 30
- Trade Name HYLUG™
- Dimension - Bolt Size fraction 3/4
- Dimension - Hole Size mm 21 mm
- Rating - KVA 35 kV
- Voltage Rating 35 kV
- Conductor - Material Copper
- Plating Type Electro-tin plated
- Dimension - Bolt Hole Size inch 0.81 in
- Color Code Orange
- Dimension - Hole Size inch 0.81 in
- Dimension - Outside Diameter inch 1.74 in
- Physical Attribute - Tongue Angle 90 Degree
- Conductor - Copper Str Size Range 1250 kcmil
- Conductor - Copper Solid Size 1300 Kcmil
- UPC 781810312933
- Type Standard Barrel, Electro-Tin Plated
- Dimension - B Length inch 2 in
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents YA453L90 Specs
