YA45N90 Hubbell Electronic Components
Part#:YA45N90
Manufacturer:Hubbell
Product Lifecycle:Active
Get a quick Quote!
Cu Tubing Compression Terminal, 1 Hole W/O InspWindow,1250 Kcmil, 3/4" Stud, Uninsulated, Long.
About the manufacturer: Hubbell is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Hubbell offers a variety of products that are specifically designed to tackle challenges faced by businesses, increase energy efficiency, enhance safety, perform well in harsh environments, streamline wiring organization, and improve grounding systems in and around buildings.
Check out the YA45N90 Hubbell price in the box on the right side or send a quick quote.
Product Details
- Connector Type Terminal
- Plated Y
- Dimension - Bolt Hole Size inch 0.56 in
- Dimension - Z inch 0.64 in
- Dimension - Thread Size 1/2
- Feature - Barrel Type Long
- Type Long Barrel, Electro-Tin Plated
- UPC 12 Digit 7818103168566
- Dimension - Height inch 5.10 in
- Conductor - Copper Str Size 1250 Kcmil
- Voltage - Maximum 35000
- Physical Attribute - Number of Holes 1
- Color Code Yellow
- Dimension - B Length inch 3.19 in
- Dimension - Outside Diameter inch 1.69 in
- Physical Attribute - Tongue Angle 90 Degree
- Conductor - Copper Str Size Range 1250 kcmil
- Physical Attribute - Tongue Type straight
- Die Index 29
- Plating Type Electro-Tin plated
- Dimension - Bolt Size fraction 1/2
- Dimension - Stud Size inch 1/2 in
- UPC 781810316856
- Dimension - Hole Size inch 0.56 in
- Dimension - Pad Width inch 2.46 in
- Voltage Rating 35 kV
- Industry Standard(s) UL 486A-486B
- UL Listed Yes
- Trade Name HYLUG™
- Feature - Barrel Style Chamfered
- Dimension - L Length Overall mm 60 mm
- Dimension - Hole Size mm 14 mm
- Conductor - Material Copper
- Dimension - Strip Length inch 3-1/4 in
- Dimension - N inch 0.63 in
- Rating - KVA 35 kV
- Conductor - Copper Solid Size 1250 Kcmil
- Minimum Pack Quantity 1
- Dimension - Length Overall inch 2.37 in
- Standards - RoHS Compliance Status CM
