ASIM-C-M12-8P-0,5M Schmersal Cable Assemblies

Product Details

• Safety functions
  Yes
• Material of the cable
  Polyurethane PUR
• Relative humidity, minimum
  30 %
• AS-i Operating voltage, minimum
  26.5 VDC
• AS-i Profile
  S-7.B.F.0
• Length of cable
  0.5 m
• Gross weight
  102 g
• Restistance to shock
  30 g / 11 ms
• AS-i Operating voltage AS-i maximum
  31.6 VDC
• AS-i Version
  V 3.0
• Terminal Connector
  Connector, M12, 8-pole, A-coded
• Width
  27.7 mm
• Storage and transport temperature, maximum
  +80 °C
• Overvoltage category
  III
• AS-i Outputs, DO 0
  LED-Output
• Note (AS-i Input module address)
  Preset to address 0, can be changed through AS-interface bus master or hand-held programming device
• Enclosure material
  Thermoplastic PBT
• Degree of protection
  IP67 to EN 60529
• Note (Relative humidity)
  non-condensing, non-icing
• Rated impulse withstand voltage Uimp
  0.8 kV
AS-i Input, Channel 1
Data bits DI 0 / DI 1 = dynamic code transmission
Note (AS-i Parameter bits)
Set the parameter outputs to "1111" (0xF)
Duration of risk, maximum
5 ms
Ambient temperature, minimum
-20 °C
Protection rating
III
Note (AS-i Operating voltage)
Protection against polarity reversal
AS-i Parameter bits, P1 ... P3
No function
Standards
EN 50295, EN 60204-1, EN 62061
Depth
22 mm
Storage and transport temperature, minimum
-25 °C
Resistance to vibrations to EN 60068-2-6
10 … 57 Hz, amplitude 0.75 mm
AS-i Outputs, DO 1 … DO 3
No Function
Reaction time, maximum
1 ms
Height
40.5 mm
Relative humidity, maximum
95 %
Degree of pollution to VDE 0100
3
AS-i Input, Channel 2
Data bits DI 2 / DI 3 = dynamic code transmission
AS-i Input module address
0
Integral System Diagnostics, status
Yes
Ambient temperature, maximum
+60 °C
Rated insulation voltage Ui
32 VDC
AS-i Current consumption, maximum
90 mA
AS-i Parameter bits, P0
Communication monitoring AS-i
