YA29L245 Hubbell Electronic Components
Part#:YA29L245
Manufacturer:Hubbell
Product Lifecycle:Active
Get a quick Quote!
250 kcmil CU, One Hole, 1/4 Stud Size, Standard Barrel, Inspection Window, Internal Chamfer, Tin Plated, UL/CSA 90° Up to 35kV, YELLOW Color Code, 16 Die Index, 45 Degree.
About the manufacturer: Hubbell is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Hubbell offers a variety of products that are specifically designed to tackle challenges faced by businesses, increase energy efficiency, enhance safety, perform well in harsh environments, streamline wiring organization, and improve grounding systems in and around buildings.
Check out the YA29L245 Hubbell price in the box on the right side or send a quick quote.
Product Details
- Plating Type Tin - Electro Plated
- Dimension - D inch 0.58 in
- UPC 12 Digit 7818103137700
- Dimension - Pad Width inch 1.11 in
- Feature - Barrel Style Chamfered
- Die Index 16
- Plated Y
- Dimension - Bolt Hole Size inch 0.27 in
- UPC 781810313770
- Dimension - L Length Overall mm 53 mm
- Physical Attribute - Tongue Angle 45 Degree
- Conductor - Copper Str Navy Size 250 (61) Navy
- Certification - ETL No
- UL Listed Yes
- Feature - Barrel Type Standard
- Trade Name HYLUG™
- Color Code Yellow
- Dimension - Hole Size inch 0.27 in
- Dimension - Strip Length inch 1-1/8
- Voltage Rating 35 kV
- Conductor - Copper Str Size 250 kcmil
- Conductor - Material Copper
- Standards - RoHS Compliance Status CM
- Physical Attribute - Number of Holes 1
- Temperature Rating 194
- Dimension - Bolt Size fraction 1/4
- Dimension - Length Overall inch 2.07 in
- Voltage - Maximum 35000
- Conductor - Copper Str Size Range 250 kcmil
- Industry Standard(s) UL 486A-486B
- Dimension - Hole Size mm 7 mm
- Dimension - Z inch 0.33 in
- Conductor - Copper DLO Size Range N/A
- Certification - UL Recognized No
- Minimum Pack Quantity 20
- Rating - KVA 35 kV
- Certification - CSA Approved Yes
- Type Long Barrel, Tin Plated
- Connector Type Terminal
- Conductor - Copper Str Navy Size Range 250 (61) Navy
- Certification - cULus No
- Dimension - B Length inch 1.06 in
- Dimension - Outside Diameter inch 0.75 in
- Dimension - N inch 0.25 in
