07509ET3E444T-W22 WEG AC Motors
Part#:07509ET3E444T-W22
Manufacturer:WEG
Alt. Part#:7891327440906
Product Lifecycle:Active
Get a quick Quote!
W22 NEMA Premium Efficiency 75 HP 8P 444/5T 3Ph 230/460//380 V 60//50 Hz IC411 - TEFC - Foot-mounted
Check out the 07509ET3E444T-W22 WEG price in the box on the right side or send a quick quote.
Product Details
- Output Rating75 HP
- Rated Speed890 rpm
- Number of Poles8 Pole
- Voltage230/460 V
- Flange TypeWithout
- Frame 444/5T
- Rated torque 443 ft.lb
- Output 75 HP (55 kW)
- No load current 80.0/40.0 A
- Altitude 1000 m.a.s.l.
- Standard NEMA MG-1
- Number of Poles 8
- Locked rotor torque 170 %
- Enclosure IC411 - TEFC
- Rated speed 890 rpm
- Breakdown torque 200 %
- Rotation¹ Both (CW and CCW)
- Rated current 187/93.4 A
- Insulation Class F
- Mounting F-1
- Flange Without
- Frequency 60 Hz
- Service factor 1.25
- Approx. weight³ 1490 lb
- Rated voltage 230/460 V
- Design B
- Noise level² 63.0 dB(A)
- Terminal box¹ Left position
- Slip 1.11 %
- Moment of inertia (J) 73.6 sq.ft.lb
- Degree of Protection IP55
- Output rating 75 HP
- L. R. Amperes 1196/598 A
- Locked rotor time 32s (cold) 18s (hot)
- Duty Cycle Cont.(S1)
- LRC 6.4x(Code H)
- Starting Method Direct On Line
- Synchronous speed 900 rpm
- Number of poles 8
- Voltage 230/460//380 V
- Temperature rise 80 K
- Ambient temperature -20°C to +40°C
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents 07509ET3E444T-W22 Specs
1-year warranty
