K50PFF50AMGRY3QPMA Banner Pick-to-Light Sensors
Part#:K50PFF50AMGRY3QPMA
Manufacturer:Banner
Alt. Part#:811505
Product Lifecycle:Active
Get a quick Quote!
K50 Pro with Pro Editor: 3-Color RGB Fixed-Field Sensor; Voltage: 12-30 V dc; Housing: Polycarbonate; IP67 IP69K; Range: 50 mm; Bimodal, NO, Momentary; Colors: Multicolor; 150 mm (6 in) 5-pin M12 PUR Pigtail QD
About the manufacturer: Banner is one of the manufacturers that offers Pick-to-Light Sensors that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the K50PFF50AMGRY3QPMA Banner price in the box on the right side or send a quick quote.
Product Details
- Weight154.22128 g
- Country Of OriginMX
- Actuation Yes
- Housing Style Base Mount - Dome Window
- Product Size (mm) 50
- Color 3 - Wavelength/Color Temp/Coordinates 522 nm
- Lumens Color 1 7.1
- Color Option 4 Cyan
- Color 1 - Wavelength/Color Temp/Coordinates 620 nm
- Color Option 6 Magenta
- Max Input Response Time (ms) 40
- Color Option 7 White
- Supply Voltage 12-30 V dc
- Max Op. Relative Humidity Non-Condensing (%) 90% @ 50°C
- Max Current Color (mA) 150
- Operation Normally Open
- Environmental Rating IP67; IP69
- Feature: Chemical Resistant No
- Primary Housing Material Polycarbonate
- Number of Colors / Segments 14
- Color Option 1 Red
- Lumens Color 2 20.5
- Lumens Color 4 15.8
- Color 5 - Wavelength/Color Temp/Coordinates 466 nm
- Pick-to-Light Function F2
- Primary Housing Color Black
- Color Input Control Multiple (One or more wires/color, enables more colors than input wires)
- Color 2 - Wavelength/Color Temp/Coordinates 576 nm
- Number of Beams 1
- Cable Length (m) 0.15
- Color 4 - Wavelength/Color Temp/Coordinates 493 nm
- Wire Selectable Function Flashing
- Max Op. Temperature (°C) 50
- Sensing Mode (General) Fixed Field
- Max Output Response Time (ms) 300
- IO Link No
- Power DC
- Connection Pigtail PUR QD
- Lumens Color 7 21.6
- Min Op. Temperature (°C) -40
- Wireless No
- Modbus RTU No
- Power Source DC
- Color Option 3 Green
- Color 7 - Wavelength/Color Temp/Coordinates 5700K
- Output Type Bipolar (NPN & PNP)
- Feature: Washdown Rated Yes
- Lumens Color 3 14.2
- Feature: Hazardous Area No
- Color Option 2 Yellow
- Input Type Bimodal (PNP/NPN)
- Activation Function Optical
- Mounting Thread M30 x 1.5
- Lumens Color 5 4
- Feature: Audible No
- Number of Input Pins/Conductors 8
- Maximum Sensing Distance (mm) 100
- Storage Temp (°C) -40 to 70
- Color Technology RGB Configurable
- Color Option 5 Blue
- Quick Disconnect Type M12 (Euro)
- Multi-Color Device Simultaneous Colors On
- Lumens Color 6 9.5
- Physical Dimensions (LxWxH or DxH mm) 50.0 x 67.3
- Primary Window Material Polycarbonate Diffused
- Pro-Editor Compatible (Discrete) Yes
- Button Operation Momentary
- USB No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
K50PFF50AMGRY3QPMA Description
K50 Pro with Pro Editor: 3-Color RGB Fixed-Field Sensor, Voltage: 12-30 V dc; Housing: Polycarbonate; IP67 IP69K, Range: 50 mm; Bimodal, NO, Momentary; Colors: Multicolor, Euro 5-pin 150 mm (6 in) PUR Pigtail
