EDS-518A-MM-ST Moxa Networking Switches
Part#:EDS-518A-MM-ST
Manufacturer:Moxa
Product Lifecycle:Active
Get a quick Quote!
Managed Gigabit Ethernet switch with 14 10/100BaseT(X) ports, 2 100BaseFX multi-mode ports with ST connectors, 2 combo 10/100/1000BaseT(X) or 1000BaseSFP slots for adding SFP-1G Series Gigabit Ethernet modules, 0 to 60°C operating temperature
Check out the EDS-518A-MM-ST Moxa price in the box on the right side or send a quick quote.
Product Details
- Alarm Contact Channels Resistive load: 1 A @ 24 VDC
- MAC Table Size 8 K
- Ethernet Interface Turbo Ring, Master, Coupler, Reserve
- Storage Temperature (package included) -40 to 85°C (-40 to 185°F)
- Standards IEEE 802.3 for 10BaseT; IEEE 802.3u for 100BaseT(X) and 100BaseFX; IEEE 802.3ab for 1000BaseT(X); IEEE 802.3z for 1000BaseSX/LX/LHX/ZX; IEEE 802.1X for authentication; IEEE 802.1D-2004 for Spanning Tree Protocol; IEEE 802.1w for Rapid Spanning Tree Protoc
- Priority Queues 4
- Overload Current Protection Supported
- Operating Temperature 0 to 60°C (32 to 140°F)
- Time 250,966 hrs
- 100BaseFX Ports (multi-mode ST connector) 2
- IGMP Groups 256
- Operating Voltage 12 to 45 VDC
- Installation DIN-rail mounting, Wall mounting (with optional kit)
- Freefall IEC 60068-2-31
- 10/100BaseT(X) Ports (RJ45 connector) 14; Auto negotiation speed; Full/Half duplex mode; Auto MDI/MDI-X connection
- Redundancy Protocols STP, MSTP, RSTP, LACP, Link Aggregation, Turbo Chain, Turbo Ring v1/v2
- LED Indicators PWR1, PWR2, FAULT, 10/100M (TP port), 100M (fiber port),1000M (Gigabit port), MSTR/HEAD, CPLR/TAIL
- IP Rating IP30
- EMS IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV; IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m; IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV; IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV; IEC 61000-4-6 CS: 10 V; IEC 61000-4-8 PFMF
- Management IPv4/IPv6, SNMPv1/v2c/v3, LLDP, Port Mirror, Back Pressure Flow Control, BOOTP, DDM, DHCP Option 66/67/82, DHCP Server/Client, Flow control, RARP, RMON, SMTP, SNMP Inform, Syslog, Telnet, TFTP
- Max. No. of VLANs 64
- Input Current 0.52 A @ 24 VDC
- EMC EN 55032/24
- Maritime DNV-GL, NK
- Combo Ports (10/100/1000BaseT(X) or 1000BaseSFP) 2
- VLAN ID Range VID 1 to 4094
- Reverse Polarity Protection Supported
- Safety EN 60950-1, UL 60950-1, CSA C22.2 No. 60950-1, UL 508
- Warranty Period 5 years
- Industrial Protocols EtherNet/IP, Modbus TCP
- Time Management NTP Server/Client, SNTP
- Housing Metal
- Hazardous Locations ATEX, Class I Division 2
- MIB MIB-II, Bridge MIB, Ethernet-like MIB, P-BRIDGE MIB, Q-BRIDGE MIB, RMON MIB Groups 1, 2, 3, 9, RSTP MIB
- Connection 2 removable 6-contact terminal block(s)
- Weight 1630 g (3.60 lb)
- EMI CISPR 32, FCC Part 15B Class A
- Digital Inputs +13 to +30 V for state 1; -30 to +3 V for state 0; Max. input current: 8 mA
- Packet Buffer Size 2 Mbits
- Input Voltage 24 VDC, Redundant dual inputs
- Ambient Relative Humidity 5 to 95% (non-condensing)
- Vibration IEC 60068-2-6
- Filter 802.1Q VLAN, Port-based VLAN, IGMP v1/v2, GVRP, GMRP
- Security HTTPS/SSL, TACACS+, Port Lock, RADIUS, SSH, Broadcast storm protection
- Console Port RS-232 (TxD, RxD, GND), 10-pin RJ45 (115200, n, 8, 1)
- Dimensions 94 x 135 x 142.7 mm (3.7 x 5.31 x 5.62 in)
- Shock IEC 60068-2-27
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents EDS-518A-MM-ST Specs
1-year warranty
